1HP Air Compressor Motor Single Phase 3450 RPM 56 Frame 5/8" Shaft Diameter
This page is affiliate-supported. Prices and availability can change after the last marketplace refresh.
About this product
This Bips 1HP Air Compressor Motor is a single-phase AC induction motor designed for replacement or building air compressor units. It operates at 115/230V, delivering a base RPM of 3450 with a 60 Hz frequency. Featuring a 56 frame and a 5/8" shaft diameter with 1.88" length, it is base-mounted and has an ODP (Open Drip-Proof) enclosure. With an insulation class F and rolled steel shell housing, it's built for durability in suitable environments.
Our take
If you're looking to replace an existing air compressor motor or building one from scratch, this Bips 1HP motor looks like a solid, versatile option. The dual voltage capability (115/230V) is a major plus, offering flexibility for different electrical setups. A 1HP motor running at 3450 RPM is common and should provide reliable power for a range of compressor pumps. The 56 frame and 5/8" shaft are standard, simplifying compatibility. Just be aware that its ODP enclosure means it's not sealed against moisture or heavy dust, so consider your operating environment. The rolled steel shell suggests a sturdy construction.
Pros & Cons
Pros
- 1HP rated load
- Dual voltage (115/230V)
- Standard 56 frame and shaft
- 3450 RPM base speed
Cons
- ODP enclosure for dry areas only
- Non-reversible rotation
- Motor only, not a complete unit
Specifications
- Brand Bips
- MPN 132717-best
- Rated Load (HP) 1
- Current Type AC
- Nominal Rated Input Voltage 115/230 V
- AC Phase Single Phase
Show all 21 specifications
- AC Motor Type
- Induction/Asynchronous
- Shaft Diameter
- 5/8 in
- Mounting Type
- Base-Mounted
- Amps
- 13.2/6.6A
- IEC Frame Size
- 56
- AC Frequency Rating
- 60 Hz
- Base RPM
- 3450 RPM
- Reversible/Non-Reversible
- Non-Reversible
- Enclosure Type
- ODP (Open Drip-Proof)
- Model
- Air Compressor Motor
- Shaft Length
- 1.88"
- IP Rating
- IP23
- Insulation Class
- F (Max 311°F)
- Housing Material
- Rolled steel shell
- Gross Weight
- 11.5kg
